Multi-Constellation for enhanced precision and reliable correction data
Build-in/external radio and Bluetooth provide multiple correction data link options
Bluetooth wireless connectivity makes configuration and diagnosis easier
3 magnet mountings offer convenient installation in challenging environments
Signal Received | GPS：L1/L2/L5 GLONASS：L1/L2 BDS）：B1/B2/B3 Galileo：E1/E5a/E5b |
Horizontal Position Accuracy (RMS) | Singlepoint：1.5m |
| Maximum Position Data Rate | 10Hz |
| Maximum CorrectionData Rate | 1Hz |
| Time to First Fix | ColdStart：<50s |
Measurement Precision (RMS) | code/cm BDS GPS GLONASS Galileo B1/L1 C/A/E1 10 10 10 10 B2/L2p(Y/L2C/E5a 10 10 10 10 B3/L5/E5b 10 10 10 10 Carrier Phase/mm B1/L1 C/A/E1 1 1 1 1 B2/2p (Y)/L2C/E5a 1 1 1 1 B3/L5/E5b 1 1 1 1 |
| Dimensions | 160 diameterx80 height(mm） |
| Weight | <950g |
| Connector | 10pin female |
| Mounting | 3xmagnet mountings 4xM4 screw inserts 1x5/8-inch screw insert |
| Power | InputVoltageRange+9VDC to +30VDC |
| Status LEDS | Power RTK status Correction data link |
| Temperature | Operating -40℃to+70℃ Storage -55℃ to +85℃ |
| Humidity | 95%non-condensing |
| Vibration | GJB150.16-2009.MIL-STD-810 |
| Compliance | CE,FCC, REACH,RoHS |
| IngressProtection Rating | IP67 |
| COMMUNICATION PORTS | 1xRS-232 serial port for user 1xRS-232 serial port for external correction data output 1xBluetooth 1x built-in radio for correction data output |
 |  |
| Utilities | Smart Industry |
 |  |
| Smart Agriculture | Asset Tracking |
