Supports unlicensed bands for Europe and the US: 863-870 MHz and 902-928 MHz
Complies with local radio regulations in Europe and the US
Strong anti-interference capability
Integrated transceiver supporting two-way communication
Long communication range with up to 1W transmit power
Strong penetration capability
Supports adaptive networking for wider coverage
Open upgrade protocol for remote firmware updates
CE and FCC certified
General Specification | |
Frequency | 863-870MHz；902-928MHz |
Operating Mode | Half-duplex |
| Modulation | LORA |
| Channels | 50 (configurable) |
| Supply Voltage | 3.3-3.6V |
| Power Consumption (Typical) | High TX Power: 4W@3.3V DV |
| Standby Power: 5mW@3.3V DV | |
| Dimensions | 9600bps / 19200bps |
| Weight | ≈3g |
| Antenna Impedance | 50ohm |
| Data Interface | 20Pin SMT |
| Air Baud Rate | 9600bps/19200bps |
| Serial Port Rate | 9600 bps/19200 bps/38400 bps/115200bps |
| RF Output Power(410-470MHz) | High Power :1W@DC 3.3V Middle Power :0.5W@DC3.3V Low Power :0.1W@DC3.3V |
| RX Sensitivity | RX Sensitivity -123dBm@BER 10-5,19200 |
| Operating Temperature | -40~+70℃ |
| Storage Temperature | -40~+85℃ |
 |  |
| USV | Robotic Lawn Mower |
 |  |
| Unmanned Delivery Vehicle | Unmanned Sweeper |
