Asset Positioning Terminal J32

The J32 is a long-standby satellite-based asset positioning terminal that integrates multi-mode positioning: 4G, BeiDou/GPS, Wi-Fi, and base station positioning. It is compatible with mainstream CAT1 cellular networks and supports the JT808 protocol. Its key features include precise positioning, SMS-based network configuration, geofencing, route playback, over-the-air (OTA) updates, and strong magnetic mounting. The J32 is ideal for asset tracking and management in sectors such as airports, power grids, smart energy, and fleet management.

BUY NOW

Details

Functional Characteristics

Ultra-long standby time with real-time connectivity
Three working modes: Power-saving / Scheduled / Smart
Multi-mode positioning: GPS + BeiDou + LBS + Wi-Fi
Strong magnetic mount for easy, tool-free installation
Super fast charging for minimal downtime and efficient use
Remote monitoring via FDD, TDD, and SMS

Specifications

Charging Time	3 hours
Initialization Time	Average Current < 90mA (DC 4.2V) Power-saving Current: < 10μA
Dimensions	104mm2456mm
Operating Frequency Bands	LTE-TDD: B38 / B39 / B40 / B41 LTE-FDD: B1 / B3 / B5 / B8
Communication Networks	TDD,FDD, GPRS
Communication Protocols	TCP(JT808, etc)
Positioning Methods	GPS, BeiDou, LBS, Wi-Fi, AGPS
Positioning Time	Cold Start: 35s (optimal) Hot Start: 1s (optimal)
Positioning Accuracy	<5m
Operating Temperature	-25℃ to +65℃
Storage Temperature	-40℃ to +85℃
Antenna	GSM Antenna: built-in GPS Antenna: built-in
Built-in Battery	6000mAh, 3.8V polymer lithium battery
