Reliable Performance Radio Modem
Compact Single Board Structure for Easy Integration
Low Power Consumption
General Specification | |
Frequencies (selectable) | 410-470MHz |
Operating Mode | Half-Duplex |
| Channel Spacing | 12.5KHz~25KHz |
| Forward Error Correction | Hamming |
| Operation Voltage | 3.3V |
| Power Dissipation (Typical) | Transmit Of High power: 4.0W@3.3V DC |
| Frequency Stability | ≤±1.0ppm |
| Dimensions | 33×26.5×3.5mm |
| Weight | 5g |
| Temperature (operation) | -40℃~+70℃ |
| Temperature (storage) | -40℃~+85℃ |
| Antenna impedance | 50ohm |
| Data Interface | 80Pin SMT |
| Antenna Interface | IPEX |
| RF Output Power | High Level(1W): 30.5±0.5dBm@ 3.3VDC Low Level(0.5W): 27.5±0.5dBm@ 3.3VDC |
| Power Stability | ±1dB |
| Harmonics | >50dB |
| Sensitivity | -117dBm@BER 10-3 ,9600bps |
| Adjacent Channel Selectivity | >50dB@25KHz |
| Data Link Rate | -117dBm@BER 10-3 ,9600bps |
| Adjacent Channel Selectivity | >50dB@25KHz |
| Data Link Rate | 4.8 kbps、9.6kbps、19.2kbps |
| Modulation Type | GMSK |
| Serial Port Baud Rate | 9600 bps、19200 bps、38400 bps、57600 bps、115200 bps |
 |  |
| Surveying and Mapping | Precision Agriculture |
