Compatible with Mainstream Radio Protocols
Support Multi-mode Data Transmit
OLED Display for Radio Operation Configuration
Versatile Features with Reliable Performance
General Specification | |
Frequency Range | 410-470MHz |
Channel Spacing | 25KHz/12.5KHz |
| Operating Mode | Half-duplex |
| Modulation Type | GMSK/4FSK |
| Channels | 36(programmable) |
| Operation Voltage | 9~36V |
| Power Consumption(typical) | High power 7.5W@12V DC Low Power 4.0W@12V DC Standby 1.2W@12V DC |
| Frequency Stability | ≤±1.0ppm |
| Size | 147.6L×83W×31.5H mm |
| Weight | Approx. 410g |
| Antenna Interface | TNC Female |
| Antenna Interface Impedance | 50ohm |
| Data Interface | LEMO 5pin |
| Air Baud Rate | 9600bps / 19200bps |
| Serial Port Baud | 9600bps / 19200bps 38400bps / 115200bps |
| RF Output Power | 410~470MHz High Power（2.0W） 33.5±1.0dBm@DC 12V Low Power (0.5W) 27.5±1.0dBm@DC 12V |
| Power Stability | ≤±1dB |
| Adjacent Channel Power | >50dB@25KHz |
| Sensitivity | -115dBm@BER 10-5，9600bps |
| Co-channel Rejection | >-12dB |
 |  |
| Surveying and Mapping | Precision Agriculture |
