Beidou/GNSS receiving frequencies: BDS B1I, B1C, GPS L1C/A, GLONASS L1, GALILEO E1
Supports single-system positioning, compatible with GPS
Supports real-time data transmission and resumable uploads
Support 4G, low-power mode and OTA update
Positioning accuracy ≤2.5m CEP
IP65 protection rating
SIM card tamper-proof
Auto-reset upon system crash
Feature | Specifications |
---|---|
BDS | B1I,B1C |
GPS | L1C/A |
GLONASS | L1 |
GALILEO | E1 |
Position Accuracy | Horizontal: <2.5 m CEP50 |
Velocity Accuracy | 0.1m/s |
Time Accuracy | 20ns |
Data Update Rate | 1Hz |
Time to First Fix | Cold start: ≤30s |
Sensitivity | Tracking: -165dBm Acquisition: -157dBm |
LTE | FDD: B1/B3/B5/B8 TDD: B34/B38/B39/B40/B41 |
Offline Storage | Offline data storage for up to 7 days, with cyclic overwriting |
Protocols | TCP,UDP,MQTT |
Operating Voltage | 9-36V; Rated Voltage: 12V |
Operating Current | < 200 mA (12V) |
Average Power Consumption | 2W (under working conditions) |
IP Rating | IP65 |
Government Fleet | Construction Fleet |
Agriculture Fleet | Airport Fleet |
