Radio Modem M1

M1 is a built-in mini transceiver designed for multiple protocols, supporting high and low power switching, air baud rate switching, serial baud rate switching, and configuration parameter changes. With a small size, light weight, and easy integration, this product exhibits excellent compatibility with radio protocols, superior reception performance, strong anti-interference capabilities, and low power consumption. It is specifically developed for the surveying market and precise agricultural applications.
Message
Details

Key Features


Compatible with Mainstream Protocols

Stable and Reliable

Long Communication Distance


Small Size and Easy to Integrate

Fast Transmission with Short Delay

 Quality Certified

Specifications

General Specification

Frequencies

410-470MHz

Operating Mode

Half-duplex

Channel Spacing

2.5KHz~25KHz

Channels 48
Operation Voltage3.3V
Power Dissipation (Typical) Transmit Of High power: 4.0W@3.3V DC
Transmit Of Low power: 2.9W@3.3V DC
Sleep State0.3W@3.3V DC
Frequency Stability≤±1.5ppm
Modem
Air Baud Rate

9600bps / 19200bps
Serial Port Baud Rate

9600bps、19200 bps、38400 bps、115200bps

Modulation TypeGMSK/4FSK

Transmitter

RF Output Power High Level(1W): 30.2±1.0dBm@DC 3.3V
Low Level(0.5W): 27.0±1.2dBm@DC 3.3V
Power Stability±1dB
Harmonics >50dB@25KHz

Receiver

Sensitivity-115dBm@BER 10-5,9600bps
CCI>50dB@25KHz
Structural Specification
Size33×26.5×3.5mm
Weight5g
Antenna InterfaceIPEX
Antenna Interface Impedance50ohm


应用场景


Surveying and MappingSmart Robotics
Precision AgricultureCommunication in Unmanned Areas
