LoRaWAN Gateway Module M302

M302 is a LoRaWAN gateway module that integrates Semtech SX1302, SX1250 and SX126X baseband and radio frequency chips. It has a listen before talk function and can be easily integrated into routers or other network equipment. It has a standard mPCIe interface and supports two communication interfaces, SPI and USB. In addition, the module also supports GNSS positioning function and supports LoRaWAN Class B working mode.

SX1302 is a new generation LoRa gateway baseband chip launched by Semtech. It is equipped with front-end SX1250 and can support spreading factors SF5~SF12. Compared with the previous generation SX1301 gateway solution, it can support higher-speed data communication, while significantly reducing power consumption, simplifying the thermal design of the gateway, and significantly improving performance.

The M302 gateway module is specially designed for M2M and IoT applications to facilitate users to develop LoRaWAN gateway devices, realize LoRaWAN network functions, and quickly bring products to market.

Message

Details

Product Features

Adopts PCI Express Mini Card 1.2 standard interface
Support SPI/USB communication interface
Supports 1 transmission channel, with transmission power up to 27dBm
With LBT(Listen Before Talk) function, monitor the channel in advance
Built in GNSS module supports PPS function output to provide accurate timestamps
Supports 8 channels reception, sensitivity as low as -139dBm@SF12, BW125 kHz
Frequency bands:EU433,IN865,EU868,AU915,US915,KR920,RU864 and AS923
Complies with LoRaWANTM Specification 1.0.3 standard, supports Class A/B/C types

Electrical Specification

Working Conditions

Parameter	Minimum	Typical	Maximum	Unit	Description
Operating Voltage	3.0	3.3	3.6	V
Operating Temperature	-40	25	85	℃
Operating Humidity	10	-	90	%RH
Storage Temperature	-40	25	85	℃
ESD_HBM	-	-	1	KV	TAMB=25℃
ESD_CDM	-	-	1	KV	TAMB=25℃

Power Consumption Parameters

Parameter	Minimum	Typical	Maximum	Unit	Description
TX Current	-	510	-	mA	@27dBm,3.3V
RX Current	-	81.6	-	mA
Standby Current	-	20	-	mA

RF Specification

Parameter	Description
Working Frequency	150MHz~960 MHz
Modulation	LoRa/(G)FSK/(G)MSK/BPSK
TX Power	27dBm(Max)
Harmonics	-40dBm

Operating Frequencies

Module	Region	Frequency	Description
M302(L)	Europe	EU433
China	CN470
M302(H)	Europe	EU868
North America	US915
Australia	AU915
Korea	KR920
Asia	AS923-1/2/3/4
India	IN865
Russia	RU864

RX Sensitivity

Parameter	Minimum	Typical	Maximum	Unit
868MHz@SF12,BW125kHz	-	-139	-	dBm
915MHz@SF12,BW125kHz	-	-139	-	dBm
470MHz@SF12,BW125kHz	-	-138	-	dBm

Structure Specification

Parameter	Description
Size	51.0(L)× 30.0(W)× 3.6(H)mm
Weight	About 6g
Antenna Interface	IPEX
Antenna Interface Impedance	50ohm
Data Interface	52Pin Mini PCI Express
